48V 3.5kWh* Commercial Battery

Click and drag image to rotate.

48V 3.5kWh* Commercial Battery

Fixed Battery Pack - Fi3.5

For maximum durability and protection, we pack our Cell Module Assembly (CMA) units in a diecast aluminum casing.
To serve both OEMs and operators, we have created a total solution that seamlessly integrates with OEMs’ equipment. Operators can expect instant, reliable power for the job at hand.
Our battery’s modular design was designed by expert engineers to apply power you can rely upon.
To get more information, download our battery literature

Click and drag image to rotate.

Features

Unmatched Durability

Diecast enclosure helps the battery withstand abuse, debris & dirt.

Maximum Efficiency

Designed to deliver a 2,000 cycle lifespan with virtually no scheduled maintenance.

Consistently Delivering Confidence

We are committed to safety and efficient operations, which is why the Battery Management System (BMS) constantly measures voltage and temperature.

Effortless Integration

There are two CANbus ports so OEMs can easily exchange information with the battery pack. One CANbus uses the J1939 automotive standard, while the other is designed for uncomplicated data transfer with the OEM's current communication network: No reprogramming of that network is required.

Uncomplicated Troubleshooting

Diagnostic protocols use standard CANbus procedures.

8 Year Commercial Limited Warranty

Vanguard now offers an 8 year commercial limited warranty for all lithium-ion battery packs. CLICK HERE for more information.

Specifications

Fi Series Name

Fi3.5

Configuration

Lithium-Ion, 14S

Nominal Voltage (V)

51.6

Top Voltage (V) per IEC 61960

58.8

Top Voltage for EV-Applications

58.1

Cutoff Voltage (V)

35.0

Nominal Capacity per IEC 61960

67.5 Ah / 3.5 kWh

Communication Protocols

J1939 (29-bit), CAN Open (11-bit)

Discharge Temperature Range

-20°C to +70°C

Charging Temperature Range

-10°C to +45°C

Marketed Durability Hours/Cycles

2000 cycles to 80% initial capacity

Parallel Capable

Yes, up to 10 batteries

Standard Charge Time

4 hours

Vanguard Charger Output Power (W)

1050 W

Battery Series

fixed

Rated Discharging Current

*Total energy measured using a 0.2C discharge per IEC 61960-3:2017
