Vanguard® 6,0 Gross kW (8,0 HP) | Horizontal Shaft Engine

Features

TransportGuard™

By simply operating one switch, the engine ignition and fuel supply are shut off ensuring equipment is ready for transport.

Over Head Valve (OHV) Design

Runs cooler and cleaner, delivering more power, longer engine life and improved fuel economy.

Large, Efficient Sediment Filter

Sediment is collected in a large, clear bowl and is drained using a convenient tool-free valve.

Full Skirt Metal Rewind

Optimized openings for maximum air flow.

Reduced Evaporative Fuel Tank Cap

Reduces emissions from the fuel tank and is mounted directly to the engine block to enhance durability.

Lo-Tone™ Muffler

Improved tonal quality and lowered noise levels allow operator to work at safe levels for longer time.

Splash Lubrication System

Delivers superior lubrication to the engine to ensure long life and reliability.

Racing Designed Connecting Rod

Efficiently improves oil flow throughout the engine; assures maximum protection of internal components.

Cartridge Air Cleaner with foam pre-cleaner (dual element)

High capacity commercial air cleaner ensures the engine is protected against air-born debris at all times in the most demanding conditions.

Larger Ignition Coil

Assures fast, easy starts.

Racing Head Gasket

Increases stability and torque.

Forged Crankshaft & Cast Iron Camshaft

Incorporates heat-treated ball bearings to minimize friction and heat build-up. Provides added durability.

Dual Ball Bearings

Provides added durability and extends engine life.

Specifications

Engine Type

Single cylinder, 4-stroke, air-cooled, OHV (Overhead Valve)

Model Number

19L1

Gross kW* @ 3’600 rpm

6,0

Gross HP* @ 3’600 rpm

8,0

Displacement (cc)

305

Cylinder

Cast Iron sleeve

Bore (mm)

79,2

Stroke (mm)

61,9

Fuel Tank Capacity (l)

3,6

Oil Capacity (l)

0,8

Compression Ratio

8.1:1

Air Cleaner

High Capacity Commercial Air Cleaner

Ignition System

Magnetron^® Electronic Ignition

Lubrication System

Splash Lubrication

Length (mm)

318

Width (mm)

421

Height (mm)

406

Dry Weight (kg)

25,9

Commercial Warranty**

3 Year Limited

Certified Power Rating

Download Power Curve

Manuals

Operator's Manual - English, Danish, Dutch, Finnish, French-European, Greek, Italian, German, Norwegian, Portuguese-European, Spanish-European, Swedish
Download Icon

Operator's Manual - English, Spanish-Colombian, French-Canadian
Download Icon

Illustrated Parts List - Chinese
Download Icon

Illustrated Parts List - Japanese
Download Icon

Illustrated Parts List - English

^{* Power levels are stated gross kilowatts per SAE J1940 as rated by Briggs & Stratton.
** See operator's manual or dealer for complete warranty details.}

Options

CARB Compliant
Tapered Crankshaft
Threaded Crankshaft
1/4" Fuel Line & Fuel Filter
Rocker Stop Switch
Tankless / Mufflerless
Emission Control System With Label
Oil Sensor
